18 Repeat these steps to create an Extrusion modifier for the inner rectangle
using a distance of 9. An extrusion modifier is created for the inner
rectangle.
19 Right-click Model Dimensions
edges of the outer box extrusion. Click a point to set the location of the
dimension. LenB1 is created for the height of the frame section.
712 | Chapter 18 Part Builder Tutorials
Add Distance. Click one of the vertical
