set to Profile. These settings specify that when you use this template in
the plan production process, the plan view of the alignment will appear
in the top viewport, and the corresponding profile will appear in the
bottom viewport.
By default, all templates that are not contained in the
Production folder
To configure your custom templates for use with the plan production
process, you must change the viewport setting as appropriate.
5 Close Civil 3D (Imperial) Plan and Profile.dwt, but do not save it.
To continue this tutorial, go to

Exercise 2: Creating View Frames

In this exercise, you will use the Create View Frames wizard to quickly create
view frames along an alignment.
View frames are rectangular areas along an alignment that represent what is
displayed in the associated viewports on the layouts (sheets) to be created.
Before you create view frames, you must have the desired alignment already
in your drawing. Depending on the type of sheets you want to produce (plan
only, profile only, or plan and profile), you may also need to have a profile
already created. If you are creating plan only sheets, then you do not need to
have a profile in the drawing.
For more information, see the AutoCAD Civil 3D Help topic Creating View
Frames.
This exercise continues from
Create view frames
1 Open Plan Production-View Frames-Create.dwg, which is located in the
tutorial drawings folder
NOTE In the Select File dialog box, ensure that Files of Type is set to Drawing
(*.dwg).
2 Click Output tab
(page 819) have their Viewport Type set to Undefined.
Exercise 2: Creating View Frames
Exercise 1: Configuring Viewports
(page 819).
Plan Production panel
Exercise 2: Creating View Frames | 807
local Template\Plan
(page 807).
(page 806).
Create View Frames .
