6.3 Test Print

6.3:A Outline
No. Indication on control panel Contents
1 NOZ. ADJ. PATTERN
2 NOZ. CHK. PATTERN
3 SET VALUE PRINT
4 HS PATTERN
5 NOZ. CHK PATTERN 2
6 4-INCH FEED PATTERN
7 2-INCH FEED PATTERN
Intermec ColorCoder V4 – Service Manual Ed. 1
This printer incorporates 7 types of test patterns with which the head
installing position, nozzle condition, and internal set values of
involved items can be checked. The test patterns can be printed in
the normal mode or service mode. Indications of patterns on the
control panel and their contents are shown below.
Registration adjusting pattern
Dot missing distinction pattern
Internal set value check pattern Width 4" or larger
Head shading test chart
Registration adjusting pattern
4-inch size feed pattern
2-inch size feed pattern
• Only No. 1-3 can be printed in the normal mode.
• For the test printing other than No.1 and 3, the printer automati-
cally adjust the temperature before starting to print so that the
head temperature increases to 32°C. If the head temperature
does not reach 32°C in 2 minutes, start printing.
1
/. If paper smaller than that listed above is used, image may not be wholly
printed or printing may not take place.
Chapter 6
Paper size 1 No. of patterns
4" x 3" or larger
4" x 3" or larger
4" x 8" or larger
All sizes
All sizes
All sizes
Troubleshooting
No. of printed sheets
1 3
2 2
3 3
1 5
1 3
1 5
1 5
