4.2 Unpacking and Installation, cont'd.
4.2:D Check of Image and Operation
Procedure
No.
1 Starting in normal mode:
Turn the power SW ON and start the operation.
When the automatic cleaning process is started and completed,
"READY" message is indicated.
Test Printing Operation:
2
1. When "READY" appears on the
display panel, press the "ON LINE" key.
"OFF LINE"
appears on the display panel.
2. Press the "MENU" key.
"PAPER TYPE"
appears on the display panel.
3. Press the right cursor key four times.
"MAINTENANCE"
appears on the display panel.
4. Press the ENTER key.
"TEST PRINT"
appears on the display panel.
5. Press the ENTER key.
"NOZZLE ADJUST PATTERN"
appears on the display panel.
6. Press the right cursor key.
"NOZZELE CHECK PATTERN"
appears on the display panel.
7. Press the ENTER key.
The "NOZZLE CHECK PATTERN" will be printed.
Intermec ColorCoder V4 – Service Manual Ed. 1
Inspection/Remarks
Use only papers of 4" x 3" or larger for test
READY
⇓ printing.
OFF LINE
⇓
This procedure shows an case of operation
using a standard label paper, 4" x 3".
PAPER TYPE
⇓
When using a different size or type of paper is
MAINTENANCE
⇓
used, select an appropriate paper size and paper
type in the "PAPER TYPE SET" menu before
TEST PRINT
⇓
printing "TEST PATTERN".
NOZ. ADJ. PATTERN
⇓
NOZ. CHK. PATTERN
Check the image quality by the nozzle check
pattern and carry out the head cleaning if neces-
sary.
