6.5 Service Mode, cont'd.
6.5:E Service Mode Menu
Hierarchy Diagram, cont'd.
b
TEST PRINT
Test print
POSITION ADJ.
Adjust mode
C
When the cutter unit
is not used.
When the cutter unit
is used.
Intermec ColorCoder V4 – Service Manual Ed. 1
NOZ. ADJ. PATTERN
NOZ. CHK. PATTERN
SET. VALUE PRINT
HS. PATTERN
NOZ. ADJ. PATTERN2
4-INCH FEED PATTERN
2-INCH FEED PATTERN
V-NOZZLE ADJ.
Vertical Registration Adjustment Value
H-NOZZLE ADJ.
Horizontal Registration Adjustment Value
STOP POS. ADJ.
Stop position adjustment
CUTTER POS. ADJ.
Cutter position adjustment
Chapter 6
Registration Adjustment Pattern
Nozzle Check Pattern
Internal Set Value Cheak Pattern
Head Shading Test Chart
Registration Adjusting Pattern
4-Inch Size Feed Pattern
2-Inch Size Feed Pattern
T-K GAP ADJ.
T-K GAP
K-C GAP ADJ.
K-C GAP
C-M GAP ADJ.
C-M GAP
M-Y GAP ADJ.
M-YGAP
Input 2 digit figure
K NOZZLE ADJ.
K NOZZLE POS.
C NOZZLE ADJ.
C NOZZLE POS.
M NOZZLE ADJ.
M NOZZLE POS.
Y NOZZLE ADJ.
Y NOZZLE POS.
STOP POS. =0.0
CUTTER POS. =0.0
Troubleshooting
=-XX
=- X
=- X
=- X
=-X
=-X
=-X
=-X
