3.2 Image Formation System, cont'd.
3.2:A BJ Head, cont'd.
Intermec ColorCoder V4 – Service Manual Ed. 1
Installing the BJ head, cont'd.
17. Execute Cleaning (B).
18. Execute Cleaning (A).
19. Check the image quality with [NOZ ADJ. PAT-TERN] and
[NOZ CHK. PATTERN]. Execute adjustment of the registra-
tion, if necessary (see Chapter 6.3 Test Print/Test Pattern).
