6.5 Service Mode, cont'd.
6.5:D List of Service Mode, cont'd.
Control Panel Indication
PRINT PAGES SET
INTERVAL SET
INT. PAGE SET
CUT INTERVAL
MARGIN SET
TOP MARGIN SET
BOT. MARGIN SET
LEFT MARGIN SET
RIGHT MARGIN SET
PAPER TYPE SET
TYPE?
TOP OF FORM SEL.
PAPER WIDTH SET.
PAPER LENGTH SET
LABEL GAP SET.
MARK WIDTH SET.
Intermec ColorCoder V4 – Service Manual Ed. 1
Paper Set Mode
Description of Operation
Sets number of pages to be printed in the range of "PRINT PAGE=" 1–99999
pages.
Sets intervals in the range of "INTERVAL=" 1–99999.
Sets number of interval pages in the range of "INT.PAGE=" 1–99 pages.
Sets number of cut interval pages in the range of "CUT INT.=" 1–99999.
Margin setting mode. Sets margins with the following 4 kinds of lower
hierarchy.
Sets upper margin in the range of "TOP MARGIN=" 00–30 mm.
Sets lower margin in the range of "BOTTOM MARGIN=" 00–30 mm.
Sets left margin in the range of "LEFT MARGIN=" 00–30 mm.
Sets right margin in the range of "RIGHT MARGIN=" 00–30 mm.
Sets the type, size, etc. of paper. There are 5 set menus PAPER TYPE 1–5, so
5 kinds of paper can be registered.
Selects the type of paper to be used from the following 5 items. "A:LABEL/
GAP" (label without mark), "B:LABEL MARKER" (label with mark),
"C:TAG/ MARKER" (tag with mark), "D:TAG/HOLE" (tag with hole),
"E:TAG/NO TOF" (tag without mark).
Sets width of paper in the range of "PAPER WIDTH=" 51–102 mm.
Sets length of paper in the range of "PAPER LENGTH=" 38–406 mm.
When the paper is label paper, sets the dimensions of the gap between labels
in the range of "LABEL GAP=" 2–99 mm.
Sets the width of the mark on the reverse side of the paper or the width of the
cut in the range of "MARK WIDTH=" 2–9 mm.
