6.8 Function Troubleshooting, cont'd
6.8:A Measures to Take Against Malfunctions, cont'd.
Error Indications "44", "45", "46", and "47"
Cause Step
BJ Heads
Connectors and Wir-
ing
Engine 2 PCB
Engine 1 PCB
BJ Heads
Intermec ColorCoder V4 – Service Manual Ed. 1
Check Point
1 Have the BJ heads been replaced?
Are the connections and wiring of the
2
following connectors in order?
Indication Connectors
Common Engine 1 PCB
Engine 2 PCB
44 Engine 2 PCB
Black head connector
45 Engine 2 PCB
Cyan head connector
46 Engine 2 PCB
Magenta head connector
47 Engine 2 PCB
Yellow head connector
Are there any wires broken or damages
3
in the flexible wires connected to the
following heads?
Indication Head
44 Black head
45 Cyan head
46 Magenta head
47 Yellow head
4 Is the problem corrected when Engine 2
PCB is replaced?
Is the problem corrected when Engine 1
5
PCB is replaced?
6
Chapter 6
Result
Yes
No
J308, J312
J406, J412
J401
J402
J403
J404
Yes
Yes
Yes
No
Troubleshooting
Corrective Action
Restart the power with service
mode.
Reconnect the connectors prop-
erly.
Replace the flexible cable corre-
sponding to the error indication.
Finished.
Finished.
Replace the BJ head correspond-
ing to the error indication.
