1.2 Specifications, cont'd.
Minimum margins
Label paper
Tag paper
Scribed image buffer capacity
Control panel LED display
Selection keys
Menu key
Detecting functions
Head cleaning function
Ink consumption
Memory card
Manual cutter
Partial rewrite function (overlay)
Counter
Options
Intermec ColorCoder V4 – Service Manual Ed. 1
Rear 1.4 mm
Front 1.5 mm
Leading edge 2.5 mm
Trailing edge 2 mm
Rear 3.4 mm
Front 3.4 mm
Leading edge 2.2 mm
Trailing edge 2.0 mm
Increasing of margins possible with menu key
2 MB / colour
READY: Machine is ready to print
DATA: Data transmission/memory card access indication
ERROR: Indication of abnormality
ON LINE: Indication of ON LINE
PAUSE: Temporary cessation/restart of printing
STOP: Printing ended;
ON LINE: Switching On/Off Line
FEED: Feeding paper in OFF LINE state
1. Paper settings (No. of sheets to be printed, intervals, interval
sheets, paper size, margins, gap marker width between labels)
2. Maintenance (cleaning, test printing, adjusting position, setting
parameters, setting interface)
3. NVRAM save
Checks paper (no paper, paper jam), checks ink cartridges, checks
ink, serviceman call, door open, no paper fed
Operates automatically and manually
17,000 sheets/cartridge
(Conditions: 12.5% Duty/colour, paper size: 4" × 3" )
Can use card (SRAM 1MB ) conforming to JEIDA Ver 4.1.
By rotating type cutter attached to paper delivery outlet.
Function available
(Exception: Printing speed slows depending on nature of rewrite
Provided. Counts only in printing for the 1-page length of 1019
lines (number of 3-inch long lines)
1. Total count (indicated on the operation panel in the service
mode)
2. Mechanical counter (positioned at the back of the main unit
inside)
Cutter unit, Rewinder, Fan-fold kit
The above information is subject to change.
