3.5 PCBs, cont'd.
3.5:C Counter PCB
Intermec ColorCoder V4 – Service Manual Ed. 1
Removing the counter PCB
1. Disconnect the connectors CN1and CN2 (2) from the counter
PCB (1).
2. Remove the two mounting screws (3) from the counter PCB (1)
and pull out the counter PCB.
1
2
Chapter 3
Mechanical System
3
Figure 3-119
146
