6.9 Layout/Functions of Electrical Parts

6.9:A Sensors and Switches
Intermec ColorCoder V4 – Service Manual Ed. 1
Name Designation Function/Nomenclature
Photointerrupter PST1
PST2
PS3
PS4
PS5
PS6
PS7
PS8
PS9
PS10
PS11
PS12
Photosensor PS1
PS2
Slide rheostat VRU1
Switch MS1
Chapter 6 Troubleshooting
TOF Inlet Sensor 1
TOF Outlet Sensor 1
Front Cover Sensor
Pressure Cam Home Position Sensor
Recovery Pump Home Positon Sensor
Cap Position Sensor 1
Cap Position Sensor 2
Head Position Sensor 1
Head Position Sensor 2
Roll Sensor
Roll Paper End Sensor
Latch Solenoid Position Sensor
TOF Inlet Sensor 2
TOF Outlet Sensor 2
Paper Width Sensing Slide Rheostat
PHS Open/Close Detection Swirch
