6.8 Function Troubleshooting, cont'd
6.8:A Measures to Take Against Malfunctions, cont'd.
Error Indications "08", "09", "10", and "11"
Cause Step
Connectors and Wir-
ing
BJ head
Engine 2 PCB
Engine 1 PCB
Intermec ColorCoder V4 – Service Manual Ed. 1
Check Point
1 Are the connections and wiring of the
following connectors in order?
Indication Connectors
Common Engine 1 PCB
Engine 2 PCB
Formatter PCB
08 Engine 2 PCB
Black head connector
09 Engine 2 PCB
Cyan head connector
10 Engine 2 PCB
Magenta head connector
11 Engine 2 PCB
Yellow head connector
2 Are there any broken wires or damages
in the flexible cable attached to the
following heads?
Indication Head
08 Black head
09 Cyan head
10 Magenta head
11 Yellow head
3 Is the problem corrected when the BJ
head corresponding to the error indica-
tion is replaced?
4 Is the problem corrected when Engine 2
PCB is replaced?
5
Chapter 6
Result
No
J307, J308,
J312
J406, J412
J105
J401
J402
J403
J404
No
Yes
Yes
No
Troubleshooting
Corrective Action
Reconnect the connectors prop-
erly.
Replace the flexible cable corre-
sponding to the error indication.
Finished.
Finished.
Replace Engine 1 PCB.
