4.2 Unpacking and Installation, cont'd.
4.2:F Relocation and
Transportation, cont'd.
Procedure
No.
Connect the power cord and turn the power on in service
3
mode, see Chapter 6.5 Service Mode.
Execute "DRAIN INK PULL" in "MAINTENANCE MODE" for
4
absorbing waste ink on the restoration tub.
Turn the power off and disconnect the power code after shut down
5
operation.
6 Take off the ink cartridges and paper roll.
7 Set the four transport cartridges into the ink room.
Place the upper head plate packing (1) on top of the upper head
8
plate and secure with filament tape (2).
Attach the PHS cover.
9
Intermec ColorCoder V4 – Service Manual Ed. 1
Transportation by Land, Air, and Sea for Middle and Long Distances, cont'd.
2
1
Chapter 4
Inspection/Remarks
Installation
