6.7 Image Troubleshooting, cont'd.
6.7:A Measures to Take Against Faulty Images, cont'd.
Vertical Streak (Marks of Rowel)
Cause Step
Rowel unit
Rowel cleaner unit
Paper delivery
rowel unit
Intermec ColorCoder V4 – Service Manual Ed. 1
Check Point
1 Is problem corrected when rowels are
cleaned?
2 Is problem corrected when rowel cleaner
is wiped with wet cloth and paper pow-
der, dirt, and ink are cleaned from the
rowel cleaner?
3 Is the problem corrected when the rowel
cleaner unit is replaced?
4 Is the paper delivery rowel deformed or
scratched?
Chapter 6 Troubleshooting
Result Corrective Action
Yes Finished.
Yes Finished.
Yes Finished.
Yes Replace the paper delivery
rowel.
