6.5 Service Mode, cont'd.
6.5:D List of Service Mode, cont'd.
Control Panel Name of Operation
Rom Version ROM version indication
O.PANEL CHECK LCD check
SYSTEM System ROM check
ROM CHECK
DRAM DRAM option check
OPT CHECK
DRAM DRAM check
CHECK (KCMY)
M. CARD CHECK Memory card check
*
Note
F.CARD CHECK Font card check
CG-ROM CHECK CG-ROM check
A/D DATA READ A/D value read
Black head A/D Black head temperature
Cyan head A/D Cyan head temperature
Magenta head A/D Magenta head temperature
Yellow head A/D Yellow head temperature
Ent. label A/D TOF inlet sensor
Exit. label A/D TOF outlet sensor
Air temp A/D Environmental temperature
Paper width A/D Paper width
TOTAL COUNT Total counter read
SERIAL No. Serial number read
*
Note: When "M. CARD CHECK" is executed, the data stored in the memory card is lost.
Intermec ColorCoder V4 – Service Manual Ed. 1
Diagnosis Mode
Description of Operation
Indicates the ROM version numbers respectively of the Formatter
PCB and the Engine 1 PCB as F:XXXX E:XXXX.
Check mode of LCD dot omission. Lights up all dots.
Executes function check of system ROM.
Indicates without DRAM option: 2 MBytes; with: 4 MBytes.
Executes check of read/write function of DRAM.
Executes check of read/write function of memory card.
Executes SUM check of font card.
Executes CG-ROM content check.
Indicates A/D read value of each sensor level.
Indicates A/D read value of black head temperature. See table 6-1.
Indicates A/D read value of cyan head temperature. See table 6-1.
Indicates A/D read value of magenta head temperature. See table
6-1.
Indicates A/D read value of yellow head temperature. See table 6-
1.
Indicates A/D read value of TOF inlet sensor 1. See table 6-2.
Indicates A/D read value of TOF outlet sensor 1. See table 6-2.
Indicates A/D read value of environmental temperature sensor
inside machine. See table 6-3.
Indicates A/D read value of paper width sensing slide resistor. See
table 6-4.
Indicates read value of total counter.
Indicates serial number of the machine.
