6.4 Head Shading, cont'd.
6.4:B Procedure to Make HS Data,
cont'd.
Intermec ColorCoder V4 – Service Manual Ed. 1
Setting Up Host Computers
1. Insert the floppy disk copied with HS data into the floppy disk
drive of the customer's host computer.
2. Copy the HS data file into the "\HS-DATA" folder. ("HS-
DATA" folder is automatically created just by installing the BJ
printer driver.)
3. The default is ready for the HS. If it is changed, open the property
of BJ LABEL/CARD PRINTER and set up to get the HS up and
running.
• Open the property of BJ LABEL/CARD PRINTER.
• Click the tag of "Details"
• Click the button of "Set up"
• Click the button of "Option"
• If "Shading output" is unclicked, click it to output with the HS.
