2.2 Image Formation System, cont'd.
2.2:C Recovery Unit, cont'd.
Sequence
Head position sensor 2 (PS9)
Head position sensor 1 (PS8)
Head motor (M3)
BJ head
MVPF : Preliminary discharge position movement
PF : Preliminary discharge
MVCP : Cap position movement
Sequence
Head position sensor 2 (PS9)
Head position sensor 1 (PS8)
Head motor (M3)
Cap position sensor 1 (PS6)
Cap position sensor 2 (PS7)
Cap motor (M4)
MVWP : Wipe position movement
WP : Wipe
MVCP : Cap position movement
Intermec ColorCoder V4 – Service Manual Ed. 1
Basic Operation Sequence
The basic operation sequence of the rcovery unit is shown below.
1. Preliminary discharge
MVPF
59 pulse
Figure 2-24
2. Head wipe
MVWP
20 pulse
Figure 2-25
Chapter 2
PF
WP
21 pulse
Operation and Timing
MVCP
86 pulse
MVCP
86 pulse
