5. Maintenance and Servicing

5.1 Parts to be re-
placed periodically

5.2 Consumable Parts

No. Parts name
1 Head assy.,
2 Pump Unit
3 PHS Unit
4 Roll motor
5 Roll motor drive gear 1-901175-00
Intermec ColorCoder V4 – Service Manual Ed. 1
This machine does not have any parts that have to be replaced
periodically.
Some of the parts of the printer may need to be replaced once or
more because of wear or damage over the period of machine
warranty. Replace them when they fail.
Parts No. Usable time Replacing timing
1-901909-00 1
1-901311-00 1
1-901300-00 1
1-901228-00 1
1
1,500,000 sheets
Recycle pump
operating 250 hours
1,500,000 sheets
1,500,000 sheets
1,500,000 sheets
Chapter 5
Remarks
12.5% driven using 4"x3" paper
