1.3 Parts of the Machine
1.3:A Front View
1.3:B Rear View
Intermec ColorCoder V4 – Service Manual Ed. 1
1
5
1. Control panel
2. PHS (Printer Head Station) unit
3. Roll cover
4. Power switch
5. Front cover
1
2
1. Sub cover
2. Power cord connector
3. Parallel interface connector
4. Manual cutter
Chapter 1
2
4
3
General Description
3
4
10
