4.2 Unpacking and Installation, cont'd.
4.2:B Installation (roll type), cont'd.
No. Procedure
14 10. Bring the paper into touch with the inner roller at the paper end
and the paper guide (inner) on the paper side and press the
"FEED" key on the control panel instantaneously.
(Paper end of about 10mm long will be fed into the PHS unit.)
* If the paper end is not fed into the PHS unit, check that the paper
end is in touch with the roller and repeat the above procedure.
11. Set the roll cover.
Intermec ColorCoder V4 – Service Manual Ed. 1
Chapter 4
Inspection/Remarks
Avoid keeping the "FEED" key pushed for
more than 2 seconds since a sheet of label is
completely fed.
If "NO PAPER FED" is indicated after start of
printing is re-quested, set the paper again and
push the "ENTER" key. Then the error is reset
and printing is started.
