6.5 Service Mode, cont'd.
6.5:D List of Service Mode, cont'd.
Indication Temperature (
3A 5
3C 6
3D 7
3F 8
41 9
43 10
44 11
46 12
48 13
4A 14
4B 15
4D 16
4F 17
50 18
52 19
54 20
55 21
57 22
59 23
5A 24
5C 25
5E 26
60 27
61 28
63 29
65 30
66 31
68 32
6A 33
6C 34
6D 35
6F 36
71 37
Intermec ColorCoder V4 – Service Manual Ed. 1
Cross-reference table for the head temperature
°
C) Remarks
Subheater ON
Subheater OFF
Table 6-1
Cross-reference table for detecting the paper
Indication
00 – 31
32 – C5
06 – FF
Indication Temperature (
73 38
74 39
76 40
78 41
79 42
7B 43
7D 44
7F 45
80 46
82 47
84 48
85 49
87 50
89 51
8B 52
8C 53
8E 54
90 55
91 56
93 57
95 58
97 59
98 60
9A 61
9C 62
9D 63
9F 64
A1 65
A2 66
A4 67
A6 68
A8 69
AA 70
Detecting the paper
The printer judges the absence of the label.
The printer judges the presence of the liner.
The printer judges the presence of the label on the liner.
Table 6-2
Chapter 6 Troubleshooting
°
C) Remarks
FAN OFF
FAN ON
Reduce printing speed
"XX Serviceman call
appears to indicates ab-
normal temperature"
