2.2 Image Formation System, cont'd.
2.2:C Recovery Unit, cont'd.
Intermec ColorCoder V4 – Service Manual Ed. 1
Head cleaning procedure, cont'd.
Cleaning during printing process (1)
After the previous cleaning 2 or 4, when the following
whichever earlier, is reached, cleaning 2 takes place.
Printing on paper equivalent to 600 sheets of standard paper (4"
× 3") with standard image (printing density 12.5%).
When mode A is selected in the "Cleaning setup" menu: 1
minute.
When mode B is selected in the "Cleaning setup" menu: 3
minutes.
Cleaning during printing process (2)
After the previous cleaning 4, when printing on paper equivalent to
2,500 sheets of standard paper (4" × 3") with standard image
(printing density 12.5%) is completed, cleaning 4 takes place.
However, if paper has exhausted during the printing process, and
printing on paper equivalent to 2,000 sheets has already completed,
cleaning 4 takes place.
Chapter 2 Operation and Timing
or ,
