6.5 Service Mode, cont'd.
6.5:E Service Mode Menu
Hierarchy Diagram
01 OFF LINE
Intermec ColorCoder V4 – Service Manual Ed. 1
The following is the menu hierarchy diagram of Service Mode.
Maintenance Mode
Maintenance mode
DIAGNOSIS
Diagnosis mode
a
SETUP CLEANING
DRAIN INK PULL
Head Print/cap
Phs Holder
WIPE
All Sequence
Fan Motor
Cleaning 1
Cleaning 2
Cleaning 3
Cleaning 4
(Cleaning 2) x 4
CLEANING (A)
CLEANING (B)
Ink supply
Rom Version
O. PANEL CHECK
SYSTEM ROM CHECK
DRAM OPT CHECK
DRAM CHECK (KCMY)
M. CARD CHECK
F. CARD CHECK
CG-ROM CHECK
A/D DATA READ
TOTAL COUNT
SERIAL No.
Chapter 6 Troubleshooting
Set up cleaning
Waste ink suction
Head moving operation*
PHS holder lock*
Wipe
Printing operation sequence
Fan motor drive
Cleaning 1
Cleaning 2
Cleaning 3
Cleaning 4
Cleaning 2 x 4
Cleaning (A)
Cleaning (B)
Ink supply
ROM version indication
Control panel(Operation panel)check
System ROM check
DRAM option check
DRAM check
Memory card check
Font card check
CG-ROM check
A/D value read-in
Total count
Serial number
