2.2 Image Formation System

2.2:A Outline
Tube connector
Tube station
Intermec ColorCoder V4 – Service Manual Ed. 1
Construction
The image formation system causes the heads to eject ink to form
images on paper based on the printing data read from the memory
card or the host computer. The system consists primarily of a head
holder unit and a recovery unit. See Figure 2-14 for the basic
construction of the image formation system.
Absorber
Restoration tub unit
Chapter 2
Head motor
Cap motor
Figure 2-14
Operation and Timing
BJ head
Recovery unit
