3.4 Pick Up/Feeder System, cont'd.
3.4:B Feeder Unit, cont'd.
Intermec ColorCoder V4 – Service Manual Ed. 1
Detaching the Feeder Unit, cont'd.
5. Disconnect the two connectors J8 and J73 (1).
1
6. Remove the four mounting screws (2) of the feeder unit (1).
2
Chapter 3 Mechanical System
Figure 3-94
1
2
Figure 3-95
