4.2 Unpacking and Installation, cont'd.
4.2:B Installation (roll type), cont'd.
No. Procedure
12 Cleaning at the time of installation:
1. While "01 OFF LINE" is displayed on
the display panel, press the MENU key.
2. Press the "ENTER" key.
3. Press the "ENTER" key.
4. Press the "ENTER" key again.
After the cleaning process is
started."NOW CLEANING" is
displayed for about 3 minutes.
Upon completion of the cleaning
process, the display is changed
to "SETUP CLEANING"
5. About 1 minutes after the completion of the set up cleaning
process, operation sound stops. Then turn OFF the power switch.
13 Turn the power off.
Open the PHS unit and remove the taped lint-free towel (1).
Intermec ColorCoder V4 – Service Manual Ed. 1
Inspection/Remarks
Check again that the head tube has been con-
nected.
01 OFF LINE
⇓
Maintenance Mode
⇓
SETUP CLEANING
⇓
TUBE CONNECT OK?
⇓
NOW CLEANING
⇓
SETUP CLEANING
1
