4.5 Parameters Menu

4.5.1 Group 3.1: Motor Settings

Table 21: Motor Nameplate Parameters
Index Parameter
P3.1.1.1 Motor Nominal Voltage
P3.1.1.2 Motor Nominal Frequency
P3.1.1.3 Motor Nominal Speed
P3.1.1.4 Motor Nominal Current
P3.1.1.5 Motor Cos Phi (Power Factor)
P3.1.1.6 Motor Nominal Power
Table 22: Motor Control Settings
Index Parameter
P3.1.2.1 Control Mode
P3.1.2.2 Motor Type
Current control
M3.1.2.3
Speed control
M3.1.2.4
Limit control
M3.1.2.5
Modulation
M3.1.2.6
Motor model
M3.1.2.7
Identification
M3.1.2.8
M3.1.2.9 Sine filter
Table 23: Current Control Settings
Index Parameter
P3.1.2.3.1 Current Control Kp
P3.1.2.3.2 Current Control Ti
46 | Danfoss A/S © 2021.09
Min Max Unit
Varies Varies V
8.00 320.00 Hz
24 19200 rpm
IH * 0.1 IH * 2 A
0.30 1.00
Varies Varies kW
Min Max Unit
0 2
0 1
Min Max
1.0 400.0
0.0005 1 000
Default ID Description
Varies 110
50 / 60 111
Varies 112
Varies 113 IH = Nominal current of the drive
Varies 120
Varies 116
Default ID Description
0 600 0 = Frequency control
1 = Speed control
2 = Torque control
0 650 0 = Induction motor
1 = PM motor
See Table
See Table
See Table
See Table
See Table
See Table
See Table
Unit Default
% 30
s 0.0050
