VACON® 3000
Application Guide
Table 164: The default values for Process Data Out in fieldbus
Data
Process Data Out 1
Process Data Out 2
Process Data Out 3
Process Data Out 4
Process Data Out 5
Process Data Out 6
Process Data Out 7
Process Data Out 8
Example
The value 5000 for Line frequency equals 50.00 Hz, because the scale is 0.01. All the monitoring values that you can find in the
Monitor menu are given the scale value.

5.5.7 Group 3.7 Supervisions

Table 165: Supervision Settings
Index Parameter
P3.7.1 Supervision #1 Item Selection
P3.7.2 Supervision #1 Mode
P3.7.3 Supervision #1 Limit
P3.7.4 Supervision #1 Limit Hysteresis
P3.7.5 Supervision #2 Item Selection
P3.7.6 Supervision #2 Mode
P3.7.7 Supervision #2 Limit
P3.7.8 Supervision #2 Limit Hysteresis
Danfoss A/S © 2021.09
Default Value
Grid active current
Last active alarm code
Last active fault code
AFE output current
DIN status word 1
DC-link voltage
Line frequency
Line voltage
Min Max Unit
5 14
0 2
-50.00 50.00 Varies
0.00 50.00 Varies
0 17
0 2
-50.00 50.00 Varies
0.00 50.00 Varies
Default ID Description
0 1431
5 = DC-link voltage
6 = Analogue input 1
7 = Analogue input 2
8 = Analogue input 3
9 = Analogue input 4
10 = Analogue input 5
11 = Analogue input 6
12 = Temperature input 1
13 = Temperature input 2
14 = Temperature input 3
0 1432
0 = Not used
1 = Low limit supervision
2 = High limit supervision
25.00 1433
5.00 1434
1 1435 See P3.8.1
0 1436 See P3.8.2
40.00 1437
5.00 1438
AB319735759636en-000101 / DPD01822 | 121
AFE Application
Scale
0.1 A
1
1
0.1 A
1
1 V
0.01 Hz
1 V
