VACON® 3000
Application Guide
•
INU application: P3.1.1.2
Find the value f
on the nameplate of the motor.
n
When this parameter changes, parameters P3.1.4.2Field Weakening Point Frequency and P3.1.4.3Voltage at Field Weakening Point start
automatically.
7.12 (ID 112) Motor Nominal Speed
Location in the menu:
•
INU application: P3.1.1.3
Find the value n
on the nameplate of the motor.
n
7.13 (ID 113) Motor Nominal Current
Location in the menu:
•
INU application: P3.1.1.4
Find the value I
on the nameplate of the motor.
n
7.14 (ID 114) Keypad Stop Button
Location in the menu:
•
INU application: P3.2.3
•
AFE application: P3.4.3
•
BCU application: P3.3.3
Use this parameter to enable the keypad stop button. When this function is enabled, a press of keypad stop button always stops the
drive (regardless of the control place). When this function is disabled, a press of keypad stop button stops the drive in local control
only.
Selection number
0
1
7.15 (ID 116) Motor Nominal Power
Location in the menu:
•
INU application: P3.1.1.6
Find the value P
on the nameplate of the motor.
n
7.16 (ID 117) I/O Control Reference A Selection
Location in the menu:
•
INU application: P3.3.1.5
Use this parameter to select the reference source when the control place is I/O A. The application set with parameter 1.2 gives the
default value.
7.17 (ID 118) PID Gain
Location in the menu:
•
INU application: P3.12.1.1
Use this parameter to adjust the gain of the PID controller. If this parameter is set to 100%, a change of 10% in the error value causes
the controller output to change by 10%.
7.18 (ID 119) PID Integration Time
Location in the menu:
•
INU application: P3.12.1.2
Use this parameter to adjust the integration time of the PID controller. If this parameter is set to 1.00 s, a change of 10% in the error
value causes the controller output to change by 10.00%/s.
Danfoss A/S © 2021.09
Selection name
Yes
No
Description
The keypad stop button is always enabled.
Limited function of the keypad stop button.
Parameter descriptions
AB319735759636en-000101 / DPD01822 | 159
