Table 120: Line PLL Monitoring
Index Monitoring value
V2.3.2.1 Line voltage
V2.3.2.2 Line frequency
V2.3.2.3 Line PLL locked
Table 121: Line Filter Observer
Index Monitoring value
V2.3.3.1 AFE Active Current
V2.3.3.2 AFE Reactive Current
V2.3.3.3 Grid Active Current
V2.3.3.4 Grid Reactive Current
V2.3.3.5 Cap Active Current
V2.3.3.6 Cap Reactive Current
V2.3.3.7 Cap Active Voltage
V2.3.3.8 Cap Reactive Voltage
V2.3.3.9 Grid Active Voltage
V2.3.3.10 Grid Reactive Voltage
V2.3.3.11 AFE output current

5.4.2 I/O Monitoring

Table 122: I/O Signal Monitoring
Index Monitoring value
V2.4.1 Slot A DIN 1, 2, 3
V2.4.2 Slot A DIN 4, 5, 6
V2.4.3 Slot B RO 1, 2, 3
V2.4.4 Analog input 1
V2.4.5 Analog input 2
V2.4.6 Analog input 3
V2.4.7 Analog input 4
V2.4.8 Analog input 5
V2.4.9 Analog input 6
V2.4.10 Slot A AO1
V2.4.15 Analog input 7
Danfoss A/S © 2021.09
Unit Scale
V 1
Hz 0.01
1
Unit Scale
A 0.1
A 0.1
A 0.1
A 0.1
A 0.1
A 0.1
V 0.1
V 0.1
V 0.1
V 0.1
A 0.1
Unit Scale ID
1 15
1 16
1 17
% 0.00 59
% 0.00 60
% 0.00 61
% 0.00 62
% 0.00 75
% 0.00 76
% 0.00 81
% 0.00 5640
AFE Application
ID Description
5510
5511
5512
0 = No
1 = Yes
ID Description
5513
5514
5515
5516
5517
5518
5519
5520
5521
5522
5530
Description
Slot A.1 as default.
Slot A.2 as default.
Slot D.1 as default.
Slot D.2 as default.
Slot E.1 as default.
Slot E.2 as default.
