Fieldbus Redundancy - Danfoss VACON 3000 Application Manual

VACON® 3000
Application Guide
Index Parameter
V5.9.1.9 Subnet mask
V5.9.1.10 Default gateway
V5.9.1.11 MAC address
V5.9.1.12 Packet rate
V5.9.1.13 Peak packet rate
Depends on fieldbuses included in drive configuration
1
Table 106: Fixed IP
Index Parameter
P5.9.1.6.1 IP address
P5.9.1.6.2 Subnet mask
P5.9.1.6.3 Default gateway
Table 107: Fieldbus General
Index Parameter
P5.13.1 Controlling Fieldbus
V5.13.2 Controlling Fieldbus

4.7.9 Fieldbus Redundancy

VACON® 3000 supports the usage of two fieldbus connections. The drive accepts control data only from the primary fieldbus. If the
primary fieldbus connection fails, the control can be automatically switched to a secondary fieldbus using the fieldbus redundancy
control. VACON® 3000 built-in fieldbus protocols support fieldbus redundancy control. The only exception is RS485 N2, which does
not support fieldbus redundancy. Recent firmware versions of fieldbus option boards also support fieldbus redundancy.
When switch on failing mode is selected, and the current fieldbus connection detects missing communication from the controller,
the switchover command is given to change to the other fieldbus connection. When switch on faulted mode is selected, and the
current fieldbus connection gets a timeout, the switchover command is given to change to the other fieldbus connection.
The switchback functionality forces a change back to the primary fieldbus connection when it is in operational state and when the
given time delay has elapsed. If the switchback functionality is deactivated, the switchover between the fieldbus connections is only
performed when the currently controlling fieldbus begins to fail or becomes faulted.
The currently controlling fieldbus protocol can be checked from the monitoring value V5.13.2 Controlling Fieldbus (ID 2610).
Table 108: Fieldbus Redundancy
Index Parameter
P5.13.3.1 Redundancy Mode
P5.13.3.2 Primary Fieldbus Connection
90 | Danfoss A/S © 2021.09
Min Max Unit Default
0 255
0 255
Min Max
Min Max
0 5
0 5
Min Max
0 2
ID Description
Unit Default
Unit Default ID
0 2539
2610
Unit Default ID
0 2606
0 2607
AB319735759636en-000101 / DPD01822
INU Application
ID Description
2529
2530
2531
Description
0 = Automatic
1 = Slot E
2 = PROFINET I/O
3 = EtherNet/IP
4 = Modbus TCP
5 = BACnet/IP
Description
0 = Disabled
1 = Switch on failing
2 = Switch on faulted
