Table 101: SNTP Monitoring
Index
Parameter
V5.5.7.2.1
SNTP status
V5.5.7.2.2
Server IP
V5.5.7.2.3
Last update time
4.7.5 Power Unit Settings
This menu contains the settings of the fan, the sine-wave filter, and the harmonic filter.
The fan operates in the optimized or the always on mode. In the optimized mode, the internal logic of the drive receives data about
the temperature and controls the fan speed. After the drive goes in the Ready state, the fan stops in 5 minutes. In the always on
mode, the fan operates in full speed, and does not stop.
The sine-wave filter keeps the overmodulation depth in limits and does not let the thermal management functions decrease the
switching frequency.
The harmonic filter can be enabled to avoid possible resonances in the DC link of the AC drive.
Table 102: Power Unit Settings
Index
Parameter
P5.6.1.1
Fan Control Mode
V5.6.1.5
Fan Lifetime ID
P5.6.1.6
Fan lifetime alarm
limit
B5.6.1.7
Fan lifetime reset ID
P5.6.4.8
Belt count
P5.6.4.9
AUX Chain Unit Count
P5.6.5.1
Sine Filter
P5.6.6.1
Harmonic Filter
4.7.6 Keypad
Table 103: The Keypad Parameters in the I/O and Hardware Menu
Index
Parameter
Min
P5.7.1
Timeout
0
Time
P5.7.2
Default
0
Page
Danfoss A/S © 2021.09
Min
Min
Max
Unit
0
1
0
200000
h
0
1
0
1
Max
Unit
De-
ID
fault
60
min
0
804
4
0
2318
Max
Unit
Default
Default
ID
Description
1
2377
0 = Always on
1 = Optimised
849
Lifetime of the fan of the drive
50000
824
Alarm limit of the fan lifetime
823
Reset the fan lifetime counter with this button.
0
6000
Number of phase module belts connected to the
control unit.
0
6001
Number of auxiliary connections to the control unit,
for example, auxiliary I/O boards, DFE, or CCA board.
0
2527
0 = Disabled
1 = Enabled
0
2497
0 = Disabled
1 = Enabled
Description
The time after which the display goes back to the page that is set
with parameter P5.7.2.
0 = Not used
The page that the display shows when the drive is powered up, or
when the time that is set with P5.7.1 is expired. If the value is set to
0, the display shows the last page that it showed.
0 = None
1 = A menu index
INU Application
ID
Description
3167
3168
3169
AB319735759636en-000101 / DPD01822 | 87
