VACON® 3000
Application Guide
Index Parameter
P3.15.4.3 Encoder Debounce Time
P3.15.4.4 Marker Debounce Time
P3.15.4.5 Marker Event Mode
P3.15.4.6 Encoder Mode
P3.15.4.7 Resolution Prescale
P3.15.4.8 Hysteresis Filter Prescale
P3.15.4.9 Encoder Resolution
P3.15.4.10 Motor Pole Pairs
P3.15.4.11 Offset Mode
P3.15.4.12 Manual Offset
P3.15.4.13 Filter Time Constant
P3.15.4.14 Frequency monitor A timeout
P3.15.4.15 Frequency monitor A re-
sponse
P3.15.4.16 HW Glitch Filter Time
P3.15.4.17 SW Detection Limit
P3.15.4.18 Encoder Repeated Error Limit
Danfoss A/S © 2021.09
Min Max Unit
0 3400 ns
0 3400 ns
0 2
0 3
1 16
0 14
0 524288
0 255
0 2
-524288 524288 deg
0.00 1000.00 ms
0.0 10000.0 ms
0 2
Hz
ms
De- ID Description
fault
250 3012
250 3013
0 3014
0 = Input M Rising Edge
1 = Input M, Gated by Z
2 = Input Z Rising Edge
0 3015
0 = Quadrature Mode
1 = Directional Pulse Mode
3 = Pulse + Direction Mode
0 3016
0 3017
Prescaler:
0 = /2
1 = /4
2 = /8
3 = /16
4 = /32
5 = /64
6 = /128
7 = /256
8 = /512
9 = /1024
10 = /2048
11 = /4096
12 = /8192
13 = /16384
14 = /32768
2048 3018
2 3019
0 3020
0 = Manual Offset
1 = Auto upon first Z pulse
2 = Auto upon first M pulse
0 3021
0.00 3022
20.0 3024
2 3025
0 = Issue fault
1 = Fallback to alternate encoder
2 = Fallback to sensorless operation
0 3027
0 = HW error disabled
0.000 3028
0 = SW error disabled
0.0 3029
AB319735759636en-000101 / DPD01822 | 77
INU Application
