The unit of measurement is degrees Celsius or Fahrenheit, depending on parameter C/F Selection (ID 1197) value.
6.9 (ID 9) Motor Temperature
Location in the menu:
•
Standard application: V2.1.10 and V2.3.12
This monitoring value shows the calculated motor temperature in percentage of the nominal working temperature.
When the value rises above 105%, motor thermal protection fault occurs.
6.10 (ID 15) SlotA DIN 1,2,3
Location in the menu:
•
INU application: V2.4.1
•
AFE application: V2.4.1
•
BCU application: V2.3.1
This monitoring value shows the status of the digital inputs 1–3 in slot A (standard I/O).
6.11 (ID 16) SlotA DIN 4,5,6
Location in the menu:
•
INU application: V2.4.2
•
AFE application: V2.4.2
•
BCU application: V2.3.2
This monitoring value shows the status of the digital inputs 4–6 in slot A (standard I/O).
6.12 (ID 17) SlotB RO 1,2,3
Location in the menu:
•
INU application: V2.4.3
•
AFE application: V2.4.3
•
BCU application: V2.3.3
This monitoring value shows the status of the relay outputs 1–3 in slot B.
6.13 (ID 18) Torque Reference
Location in the menu:
•
Standard application: V2.3.14
This monitoring value shows the final torque reference for motor control.
6.14 (ID 20) PID Setpoint
Location in the menu:
•
Standard application: V2.1.11 and V2.7.1
This monitoring value shows the value of the PID setpoint signal in process units. You can use the Process Unit Selection parameter
(ID 1036) to select the process unit (see
6.15 (ID 21) PID Feedback
Location in the menu:
•
Standard application: V2.1.12 and V2.7.2
This monitoring value shows the value of the PID feedback signal in process units. You can use the Process Unit Selection parameter
(ID 1036) to select the process unit (see
6.16 (ID 22) PID Error
Location in the menu:
•
Standard application: V2.1.13 and V2.7.3
This monitoring value shows the error value of the PID controller.
Danfoss A/S © 2021.09
7.221 (ID 1036) Process Unit
Selection).
7.221 (ID 1036) Process Unit
Selection).
Monitoring value descriptions
AB319735759636en-000101 / DPD01822 | 137
