VACON® 3000
Application Guide
Index Parameter
P3.5.2.6.3 AI6 Signal Range
P3.5.2.6.4 AI6 Custom. Min
P3.5.2.6.5 AI6 Custom. Max
P3.5.2.6.6 AI6 Signal Inversion
Shows only the parameters for the outputs on option boards in slots C, D, and E. Make the selections as in RO1 Function
(P3.5.3.2.1). This group or these parameters are not visible if there are no digital outputs in slots C, D, or E.
Table 56: Digital Output Settings on Standard I/O Board
Index Parameter
P3.5.3.2.1 RO1 Func-
tion
Danfoss A/S © 2021.09
Min
0
-160.00
-160.00
0
N O T I C E
Min Max Unit De-
fault
0 40 3
Max Unit Default
1 0
160.00 % 0.00
160.00 % 100.00
1 0
ID Description
11001 0 = Not used
1 = Test (always closed)
2 = Ready
3 = Run
4 = Fault
5 = Fault inverted
6 = Alarm
7 = Reverse
8 = At speed
9 = Thermistor fault
10 = Motor regulator active
11 = Start signal active
12 = Keypad control active
13 = I/O B control activated
14 = Limit supervision1
15 = Limit supervision2
16 = Jogging activated
17 = Preset frequency active
18 = Quick stop active
19 = PID in Sleep mode
20 = Fieldbus Control- Word B13
21 = Fieldbus Control- Word B14
22 = Fieldbus Control- Word B15
23 = Fieldbus Process- Data1.B0
24 = Fieldbus Process- Data1.B1
25 = Fieldbus Process- Data1.B2
26 = Mechanical brake (Open brake command)
27 = Mechanical brake inverted
28 = Motor Switch Open
29 = Mains contactor permissive
30 = Mains contactor close
31 = Precharge permissive
32 = INU run enable
INU Application
ID Description
201 See P3.5.2.1.3.
203 See P3.5.2.1.4.
204 See P3.5.2.1.5.
209 See P3.5.2.1.6.
