VACON® 3000
Application Guide

4.5.8 Group 3.8 Supervisions

Table 62: Supervision Settings
Index Parameter
P3.8.1 Supervision #1 Item Selection
P3.8.2 Supervision #1 Mode
P3.8.3 Supervision #1 Limit
P3.8.4 Supervision #1 Limit Hysteresis
P3.8.5 Supervision #2 Item Selection
P3.8.6 Supervision #2 Mode
P3.8.7 Supervision #2 Limit
P3.8.8 Supervision #2 Limit Hysteresis

4.5.9 Group 3.9: Protections

Table 63: General protection settings
Index Parameter
P3.9.1.1 Preset Alarm Frequency
P3.9.1.2 Response to External Fault
P3.9.1.3 Undervoltage Fault
P3.9.1.4 Response to Output Phase
Fault
66 | Danfoss A/S © 2021.09
Min Max Unit
0 14
0 2
-50.00 50.00 Varies
0.00 50.00 Varies
0 17
0 2
-50.00 50.00 Varies
0.00 50.00 Varies
Min Max Unit Default
P3.3.1.1 P3.3.1.2 Hz 25.00
0 3 2
0 1 0
0 3 2
Default ID Description
0 1431
0 = Output frequency
1 = Frequency reference
2 = Motor current
3 = Motor torque
4 = Motor power
5 = DC-link voltage
6 = Analogue input 1
7 = Analogue input 2
8 = Analogue input 3
9 = Analogue input 4
10 = Analogue input 5
11 = Analogue input 6
12 = Temperature input 1
13 = Temperature input 2
14 = Temperature input 3
0 1432
0 = Not used
1 = Low limit supervision
2 = High limit supervision
25.00 1433
5.00 1434
1 1435 See P3.8.1
0 1436 See P3.8.2
40.00 1437
5.00 1438
ID Description
183
701 0 = No action
1 = Alarm
2 = Fault (Stop according to stop
function)
3 = Fault (Stop by coasting)
727 0 = Fault stored in history
1 = Fault not stored in history
702 See P3.9.1.2.
AB319735759636en-000101 / DPD01822
INU Application
