Programming
3.
Press [
in the Quick Menu.
4. Press [OK] to select a parameter.
5.
Press [
setting.
6. Press [OK] to accept the change.
7. To exit, press either [Back] twice to enter Status,
or press [Menu] once to enter Main Menu.
Illustration 7.9 Indicating Quick Menu Mode
7 7

7.4 Quick Menu Parameters

7.4.1 Quick Menu Parameters - Basic
Settings QM1
Below are descriptions of all parameters found in the Quick
Menu.
＊=Factory setting.
1-20 Motor Power [kW]/[HP] (P
Option:
[1] 0.09 kW/0.12 HP
[2] 0.12 kW/0.16 HP
[3] 0.18kW/0.25 HP
[4] 0.25 kW/0.33 HP
[5] 0.37kW/0.50 HP
[6] 0.55 kW/0.75 HP
[7] 0.75 kW/1.00 HP
[8] 1.10 kW/1.50 HP
[9] 1.50 kW/2.00 HP
[10] 2.20 kW/3.00 HP
[11] 3.00 kW/4.00 HP
[12] 3.70 kW/5.00 HP
[13] 4.00 kW/5.40 HP
[14] 5.50 kW/7.50 HP
[15] 7.50 kW/10.0 HP
[16] 11.00 kW/15.00 HP
[17] 15.00 kW/20.00 HP
[18] 18.50 kW/25.00 HP
[19] 22.00 kW/29.50 HP
[20] 30.00 kW/40.00 HP
60
VLT
▲ ▼
] [ ] to browse through the parameters
▲ ▼
] [ ] to change the value of a parameter
)
m.n
Function:
Enter motor power from nameplate
data.
Two sizes down, one size up from
nominal VLT rating.
®
Micro Drive FC 51 Design Guide
NOTICE
Changing this parameter affects parameter 1-22 to 1-25,
1-30, 1-33 and 1-35.
1-22 Motor Voltage (U_
Range:
230/400 V
1-23 Motor Frequency (f_
Range:
50 Hz [20-400 Hz] Enter motor frequency from nameplate
*
1-24 Motor Current (I_
Range:
M-type dependent
1-25 Motor Nominal Speed (n_
Range:
M-type Dependent
1-29 Automatic Motor Tuning (AMT)
Option:
[0] Off
*
[2] Enable
AMT
3-02 Minimum Reference
Range:
0.00 [-4999-4999] Enter value for minimum reference.
*
MG02K302 - Rev. 2013-12-03
)
m.n
Function:
[50-999 V] Enter motor voltage from nameplate
data.
)
m.n
Function:
data.
)
m.n
Function:
[0.01-100.00 A] Enter motor current from
*
nameplate data.
)
m.n
Function:
[100-9999 RPM] Enter motor nominal
*
speed from nameplate
data.
Function:
Use AMT to optimise motor performance.
NOTICE
This parameter cannot be changed while
motor runs.
1. Stop the frequency converter - make
sure motor is at standstill
2. Select [2] Enable AMT
3. Apply start signal
- Via LCP: Press [Hand On]
- Or in Remote On mode: Apply start
signal on terminal 18
AMT function is disabled.
AMT function starts running.
NOTICE
To gain optimum tuning of the frequency
converter, run AMT on a cold motor.
Function:
The sum of all internal and external
references are clamped (limited) to the
minimum reference value, 3-02 Minimum
Reference.
