VACON® 3000
Application Guide
Index
Monitoring value
V2.12.6.4
HEX status word
V2.12.6.5
ENC HX status word
V2.12.6.6
DC capacitor status word
Table 20: Interlocks @ Last Fault Monitoring Values
Index
Monitoring value
V2.12.7.1
GSW UFES status word fault
V2.12.7.2
MCB status word fault
V2.12.7.3
Leak detection status word fault
V2.12.7.4
ENC HX status word fault
V2.12.7.5
HEX status word fault
V2.12.7.6
DC capacitor status word fault
Danfoss A/S © 2021.09
Unit
Scale
ID
1
3573
1
3572
1
3584
Unit
Scale
ID
3582
1
3576
1
3577
1
3578
1
3579
3585
INU Application
Description
b6 = LD No Leak 3
b7 = LD No Leak 4
b0 = HX Cooling Ok 1
b1 = HX Cooling Ok 2
b2 = HX Cooling Ok 3
b3 = HX Cooling Ok 4
b0 = ENC HX 1
b1 = ENC HX 2
b2 = ENC HX 3
b3 = ENC HX 4
b4 = ENC FAN 1.1
b5 = ENC FAN 1.2
b6 = ENC FAN 1.3
b7 = ENC FAN 2.1
b8 = ENC FAN 2.2
b9 = ENC FAN 2.3
b10 = ENC FAN 3.1
b11 = ENC FAN 3.2
b12 = ENC FAN 3.3
b13 = ENC FAN 4.1
b14 = ENC FAN 4.2
b0 = DC Choke Ok 1
b1 = DC Choke Ok 2
b2 = DC Cap Ok 1
b3 = DC Cap Ok 2
b4 = DC Cap Ok 3
b5 = DC Cap Ok 4
Description
See ID 3575 in
Table
19.
See ID 3570 in
Table
19.
See ID 3571 in
Table
19.
See ID 3572 in
Table
19.
See ID 3573 in
Table
19.
See ID 3584 in
Table
19.
AB319735759636en-000101 / DPD01822 | 45
