VACON® 3000
Application Guide
Selection Selection name
number
30 Main contactor close
31 Precharge permissive
32 INU run enable
33 Precharge ready
34 Precharge started
35 Precharge inhibit
36 Precharge coil
37 HXL coil
38 MV HX coil
39 LV HX coil
40 MCB coil
Selection Selection name
number
0 Not used
1 TEST (Always closed)
2 Ready
3 Run
4 General fault
5 General fault inverted
6 General alarm
7 Reversed
8 At speed
9 Thermistor fault
10 Motor regulator activated
11 Start signal active
12 Keypad control active
13 Limit supervision 1
14 Limit supervision 2
15 Fieldbus Control Word bit 13
16 Fieldbus Control Word bit 14
17 Fieldbus Control Word bit 15
266 | Danfoss A/S © 2021.09
Description
The main contactor is closed.
The permission to start the precharge operation is given
INU operation is enabled.
The precharge operation is ready to start.
The precharge operation started.
The precharge operation is prevented.
Description
The output is not used.
The AC drive is ready to operate.
The AC drive operates (the motor runs).
A fault trip occurred.
A fault trip did not occur.
An alarm occurred.
The reverse command is given.
The output frequency has become the same as the set frequency reference.
A thermistor fault occurred.
One of the limit regulators (for example current limit or torque limit) is activated.
The start command of the drive is active.
The selection is keypad control (the active control place is keypad).
The limit supervision activates if the signal value goes below or above the set
supervision limit (P3.8.3 or P3.8.7).
The limit supervision activates if the signal value goes below or above the set
supervision limit (P3.8.3 or P3.8.7).
The digital (relay) output control from the Fieldbus control word bit 13.
The digital (relay) output control from the Fieldbus control word bit 14.
The digital (relay) output control from the Fieldbus control word bit 15.
Parameter descriptions
