When switch on failing mode is selected, the primary fieldbus connection begins to fail sending messages to the drive. Then the
switchover command is given to change to the secondary fieldbus connection. When switch on faulted mode is selected, and the
primary fieldbus connection gets a timeout, the switchover command is given to change to the secondary fieldbus connection.
The switchback functionality forces a change back to the primary fieldbus connection when it is in operational state and when the
given time delay has elapsed. If the switchback functionality is deactivated, the switchover between the fieldbus connections is only
performed when the currently controlling fieldbus begins to fail or becomes faulted.
The currently controlling fieldbus protocol can be checked from the monitoring value V5.13.2 Controlling Fieldbus (ID 2610).
Table 188: Fieldbus Redundancy
Index Parameter
P5.13.3.1 Redundancy Mode
P5.13.3.2 Primary Fieldbus Connection
P5.13.3.3 Secondary Fieldbus Connection
P5.13.3.4 Switchover Timeout
P5.13.3.5 Switchback Timeout
V5.13.3.6 Switchover Counter

5.7.10 Aux Chain

The contents of the menu depend on the units connected to the aux chain. The number of units is configured with parameter AUX
Chain Unit Count (ID 6001). The parameters in
unit has a similar menu and set of parameters (Aux 15, Aux 16, Aux 17).
Table 189: Aux 14 Parameters in the I/O and Hardware Menu
Index Parameter
V5.14.1.1 Board status
V5.14.1.2 Breaker enable status
V5.14.1.3 Breaker switch status
V5.14.1.4 Measurement configuration
switch
V5.14.1.5 Digital input 1–16
V5.14.1.6 Digital input 17–32
V5.14.1.7 DigOUT AUX 14
V5.14.1.8 Analog input 1
V5.14.1.9 Analog input 1 mode
V5.14.1.10 Analog input 2
V5.14.1.11 Analog input 2 mode
Danfoss A/S © 2021.09
Min Max
0 2
0 65535
0 65535
Table 189 are for the first unit connected to the Aux chain (Aux 14). Each connected
Min Max Unit Default
0.00 100.00 % 0.00
0.00 100.00 % 0.00
Unit Default ID
0 2606
0 2607
0 2608
ms 0 2609
s 10 2612
2611
ID Description
29001
29002
29003
29004
29005
29006
29015
29007 Status of the analog input signal
29008
Shows the mode that is set for the analog
input signal. The selection is made with a
DIP switch on the board.
1 = 0...20 mA
3 = 0...10 V
29009 Status of the analog input signal
29010
Shows the mode that is set for the analog
input signal. The selection is made with a
DIP switch on the board.
AB319735759636en-000101 / DPD01822 | 133
AFE Application
Description
0 = Disabled
1 = Switch on failing
2 = Switch on faulted
