Table 48: Flux Braking Parameters
Index Parameter
P3.4.5.1 Flux Braking
P3.4.5.2 Flux Braking Current

4.5.5 Group 3.5: I/O Configuration

Table 49: Digital Input Settings
Index Parameter
P3.5.1.1 Control Signal 1 A
P3.5.1.2 Control Signal 2 A
P3.5.1.3 Control Signal 3 A
P3.5.1.4 Control Signal 1 B
P3.5.1.5 Control Signal 2 B
P3.5.1.6 Control Signal 3 B
P3.5.1.7 I/O B Control Force
P3.5.1.8 I/O B Reference Force
P3.5.1.9 Fieldbus Control Force
P3.5.1.10 Keypad Control Force
P3.5.1.11 External Fault Close
P3.5.1.12 External Fault Open
P3.5.1.13 Fault Reset Close
P3.5.1.14 Fault Reset Open
P3.5.1.15 Run Enable
P3.5.1.16 Run Interlock 1
P3.5.1.17 Run Interlock 2
P3.5.1.18 Ramp 2 Selection
Danfoss A/S © 2021.09
Min Max Unit
0 1
0 IL A
Min Max Unit Default
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.2
DigIN Slot0.1
DigIN Slot0.1
DigIN SlotA.1
DigIN Slot0.2
DigIN Slot0.2
DigIN Slot0.1
Default ID Description
0 520 0 = Disabled
1 = Enabled
IH 519
ID Description
403
404
434
423
424
435
425 CLOSED = Force the control place to
I/O B
343 CLOSED = I/O reference B (P3.3.1.6)
gives the frequency reference
411
410
405 OPEN = OK
CLOSED = External fault
406 OPEN = External fault
CLOSED = OK
414 CLOSED = Resets all active faults
213 OPEN = Resets all active faults
407
1041
1042
408 OPEN = Ramp 1 Shape, Acceleration
Time 1, and Deceleration Time 1.
AB319735759636en-000101 / DPD01822 | 57
INU Application
