Table 70: AI low protection settings
Index
Parameter
P3.9.8.1
Analog Input Low Protection
P3.9.8.2
Analog Input Low Fault
Table 71: User Defined Fault 1
Index
Parameter
P3.9.9.1
User Defined Fault 1
P3.9.9.2
Response to User Defined
Fault 1
Table 72: User Defined Fault 2
Index
Parameter
P3.9.10.1
User Defined Fault 2
P3.9.10.2
Response to User Defined
Fault 2
Table 73: Speed Error
Index
Parameter
P3.9.11.1
Speed error fault response
P3.9.11.2
Speed error limit
P3.9.11.3
Speed error delay
P3.9.11.4
Over speed fault response
70 | Danfoss A/S © 2021.09
Min
Max
Unit
Default
0
2
2
0
5
0
Min
Max
Unit
Default
-
-
DigIN Slot0.1
0
3
3
Min
Max
Unit
Default
-
-
DigIN Slot0.1
0
3
3
Min
Max
Unit
Default
0
3
0
%
0.00
s
0.00
0
ID
Description
767
0 = No protection
1 = Protection enabled in Run state
2 = Protection enabled in Run and Stop state
700
0 = No action
1 = Alarm
2 = Alarm + preset fault frequency (P3.9.1.1)
3 = Alarm + previous frequency reference
4 = Fault (Stop according to stop mode)
5 = Fault (Stop by coasting)
ID
Description
15523
OPEN = No operation
CLOSED = Fault activated
15525
0 = No action
1 = Alarm
2 = Fault (Stop according to stop function)
3 = Fault (Stop by coasting)
ID
Description
15524
OPEN = No operation
CLOSED = Fault activated
15526
0 = No action
1 = Alarm
2 = Fault (Stop according to stop function)
3 = Fault (Stop by coasting)
ID
Description
4032
0 = No action
1 = Alarm
2 = Fault (Stop according to stop function)
3 = Fault (Stop by coasting)
4030
4031
780
See P3.9.11.1.
