VACON® 3000
Application Guide
5 AFE Application
5.1 Overview
The AFE application is used to control the AFE phase modules of the VACON® 3000.
It is possible to control the drive from the control panel (keypad), Fieldbus, or I/O terminal.
It is possible to configure all the drive outputs freely. There is 1 analog output and 3 relay outputs (Run, Fault, Ready) available on
the basic I/O board.
5.2 Menu Structure
The data of the AC drive is in menus and submenus. To move between the menus, use the arrow buttons Up and Down in the
keypad. To go into a group or an item, push the [OK] button. To go back to the level where you were before, push the [BACK/RESET]
button.
On the display, you see your current location in the menu, for example M3.2.1. You also see the name of the group or item in your
current location.
Table 116: Menu Structure
Menu
M1 Quick setup
M2 Monitor
M3 Parameters
M4 Diagnostics
94 | Danfoss A/S © 2021.09
Function
Quick setup
Multimonitor
AFE monitor
I/O
Extras/Advanced
Maintenance counters
Fieldbus data
Precharge
Basic parameters
Control parameters
Precharge
Start/Stop setup
I/O Configuration
Fieldbus data mapping
Supervisions
Protections
Automatic reset
Application settings
Maintenance counters
Active faults
Reset faults
Fault history
Total counters
AFE Application
AB319735759636en-000101 / DPD01822
