4.7 I/O and Hardware Menu

4.7.1 Basic I/O

Table 97: The Basic I/O Parameters in the I/O and Hardware Menu
Index Parameter
V5.1.1 Digital Input 1
V5.1.2 Digital Input 2
V5.1.3 Digital Input 3
V5.1.4 Digital Input 4
V5.1.5 Digital Input 5
V5.1.6 Digital Input 6
V5.1.7 Analog Input 1 Mode
V5.1.8 Analog Input 1
V5.1.9 Analog Input 2 Mode
V5.1.10 Analog Input 2
V5.1.11 Analog Output 1
Mode
V5.1.12 Analog Output 1
V5.1.13 Relay Output 1
V5.1.14 Relay Output 2
V5.1.15 Relay Output 3

4.7.2 Option Board Slots

The parameters in this menu are different for all the option boards. The parameters of the installed option board is shown. If there is
no option board in the slots C, D or E, no parameters are shown. See more about the location of the slots in chapter
Information on the Programming.
When an option board is removed, the fault code 39 and the fault name Device removed show on the display.
Danfoss A/S © 2021.09
Min Max Unit Default
0 1 0
0 1 0
0 1 0
0 1 0
0 1 0
0 1 0
1 3 3
0 100 % 0.00
1 3 3
0 100 % 0.00
1 3 1
0 100 % 0.00
0 1 0
0 1 0
0 1 0
ID Description
2502 Status of the digital input signal
2503 Status of the digital input signal
2504 Status of the digital input signal
2505 Status of the digital input signal
2506 Status of the digital input signal
2507 Status of the digital input signal
2508
Shows the mode that is set for the analog input signal.
The selection is made with a DIP switch on the control
board.
1 = 0...20mA
3 = 0...10V
2509 Status of the analog input signal
2510
Shows the mode that is set for the analog input signal.
The selection is made with a DIP switch on the control
board.
1 = 0...20mA
3 = 0...10V
2511 Status of the analog input signal
2512
Shows the mode that is set for the analog input signal.
The selection is made with a DIP switch on the control
board.
1 = 0...20mA
3 = 0...10V
2513 Status of the analog output signal
2514 Status of the relay output signal
2515 Status of the relay output signal
2516 Status of the relay output signal
