P3.2.9 Start Delay
P3.2.10 Remote to Local Function
P3.2.11 Restart delay
P3.2.12 Short restart delay

4.5.3 Group 3.3: References

Table 36: Frequency Reference Parameters
Index Parameter
P3.3.1.1 Minimum Frequency Reference
P3.3.1.2 Maximum Frequency Reference
P3.3.1.3 Positive Frequency Reference Limit
P3.3.1.4 Negative Frequency Reference Limit
P3.3.1.5 I/O Control Reference A Selection
P3.3.1.6 I/O Control Reference B Selection
P3.3.1.7 Keypad Control Reference Selection
P3.3.1.8 Keypad Reference
P3.3.1.9 Keypad Direction
52 | Danfoss A/S © 2021.09
Min Max Unit Default
0.000 60.000 s 0.00
0 2 2
s 0.0
s 0.0
Min Max
0.00 P3.3.1.2
P3.3.1.1 320.00
-320.0 320.0
-320.0 320.0
1 10
1 10
1 10
P3.3.1.1 P3.3.1.2
0 1
ID Description
1 = State
524
181 0 = Keep Run
1 = Keep Run & Reference
2 = Stop
1424
672
Unit Default ID Description
Hz 0.00 101
Hz 0.00 102
Hz 320.00 1285
Hz -320.00 1286
6
117 1 = Preset Frequency 0
2 = Keypad reference
3 = Fieldbus
4 = AI1
5 = AI2
6 = AI1+AI2
7 = PID reference
8 = Motor potentiometer
9 = Joystick reference
10 = Jogging reference
4
131 See P3.3.1.5.
2
121 1 = Preset Frequency 0
2 = Keypad reference
3 = Fieldbus
4 = AI1
5 = AI2
6 = AI1+AI2
7 = PID reference
8 = Motor potentiometer
9 = Joystick reference
10 = Jogging reference
Hz 0.00 184
0 123 0 = Forward
