5.5.5 Group 3.5: I/O Configuration

Table 149: Digital Input Settings
Index Parameter
P3.5.1.1 Control Signal 1 A
P3.5.1.2 Control Signal 2 A
P3.5.1.3 Control Signal 3 A
P3.5.1.4 Fieldbus Control Force
P3.5.1.5 Keypad Control Force
P3.5.1.6 External Fault Close
P3.5.1.7 External Fault Open
P3.5.1.8 Fault Reset Close
P3.5.1.9 Fault Reset Open
P3.5.1.10 Run Enable
P3.5.1.11 Run Interlock 1
P3.5.1.12 Run Interlock 2
P3.5.1.13 Maintenance counter 1 reset
P3.5.1.14 Parameter Set 1/2 Selection
Power on
P3.5.1.15
Danfoss A/S © 2021.09
Min Max Unit Default
0 1 0
0 2 0
Min Max Unit Default
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.2
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.2
DigIN Slot0.2
DigIN Slot0.2
DigIN Slot0.1
DigIN Slot0.1
DigIN Slot0.1
ID Description
• Ctrl sgn 1 = Start
• Ctrl sgn 2 = Reverse
Logic = 4
• Ctrl sgn 1 = Start (edge)
• Ctrl sgn 2 = Reverse
889 0 = A rising edge is necessary
1 = State
181 0 = Keep Run
1 = Keep Run & Reference
2 = Stop
ID Description
403
404
434
411
410
405 OPEN = OK
CLOSED = External fault
406 OPEN = External fault
CLOSED = OK
414 CLOSED = Resets all active faults
213 OPEN = Resets all active faults
407
1041
1042
490
496 OPEN = Parameter set 1
CLOSED = Parameter set 2
3550
