VACON® 3000
Application Guide
Selection Selection name
number
18 Fieldbus Process Data In1 bit 0
19 Fieldbus Process Data In1 bit 1
20 Fieldbus Process Data In1 bit 2
21 Main contactor permissive
22 Main contactor close
23 Precharge permissive
24 INU run enable
25 Precharge ready
26 Precharge started
27 Precharge inhibit
28 Precharge coil
29 HXL coil
30 MV HX coil
31 LV HX coil
32 MCB coil
7.584 (ID 11002) RO1 ON Delay
Location in the menu:
• INU application: P3.5.3.2.2
• AFE application: P3.5.3.2.2
• BCU application: P3.4.3.2.2
Use this parameter to set the ON delay for the relay output.
7.585 (ID 11003) RO1 OFF Delay
Location in the menu:
•
INU application: P3.5.3.2.3
•
AFE application: P3.5.3.2.3
•
BCU application: P3.4.3.2.3
Use this parameter to set the OFF delay for the relay output.
7.586 (ID 11004) RO2 Function
Location in the menu:
• INU application: P3.5.3.2.4
• AFE application: P3.5.3.2.4
• BCU application: P3.4.3.2.4
Use this parameter to select a function or a signal that is connected to the relay output. See
7.587 (ID 11005) RO2 ON Delay
Location in the menu:
Danfoss A/S © 2021.09
Description
The digital (relay) output control from the Fieldbus Process Data In1, bit 0.
The digital (relay) output control from the Fieldbus Process Data In1, bit 1.
The digital (relay) output control from the Fieldbus Process Data In1, bit 2.
The permission to close the main contactor is given.
The main contactor is closed.
The permission to start the precharge operation is given
INU operation is enabled.
The precharge operation is ready to start.
The precharge operation started.
The precharge operation is prevented.
Parameter descriptions
7.583 (ID 11001) RO1 Function.
