VACON® 3000
Application Guide
Index
Parameter
P3.12.2.5
Setpoint source 1 selection
P3.12.2.6
Setpoint 1 minimum
P3.12.2.7
Setpoint 1 maximum
P3.12.2.8
Setpoint source 2 selection
P3.12.2.9
Setpoint 2 minimum
P3.12.2.10
Setpoint 2 maximum
Table 79: Feedback Settings
Index
Parameter
P3.12.3.1
Feedback Function Gain
P3.12.3.2
Feedback 1 Source Selection
P3.12.3.3
Feedback 1 Minimum
P3.12.3.4
Feedback 1 Maximum
74 | Danfoss A/S © 2021.09
Min
Max
Unit
0
16
-200.00
200.00
%
-200.00
200.00
%
0
22
-200.00
200.00
%
-200.00
200.00
%
Min
Max
Unit
-2100.0
2100.0
%
0
14
-200.00
200.00
%
-200.00
200.00
%
Default
ID
Description
1
332
0 = Not used
1 = Keypad setpoint 1
2 = Keypad setpoint 2
3 = AI1
4 = AI2
5 = AI3
6 = AI4
7 = AI5
8 = AI6
9 = ProcessDataIn1
10 = ProcessDataIn2
11 = ProcessDataIn3
12 = ProcessDataIn4
13 = ProcessDataIn5
14 = ProcessDataIn6
15 = ProcessDataIn7
16 = ProcessDataIn8
0.00
1069
100.00
1070
2
431
See P3.12.2.5.
0.00
1073
See P3.12.2.6.
100.00
1074
See P3.12.2.7.
Default
ID
Description
100.0
1058
2
334
0 = Not used
1 = AI1
2 = AI2
3 = AI3 4 = AI4
5 = AI5 6 = AI6
7 = ProcessDataIn1
8 = ProcessDataIn2
9 = ProcessDataIn3
10 = ProcessDataIn4
11 = ProcessDataIn5
12 = ProcessDataIn6
13 = ProcessDataIn7
14 = ProcessDataIn8
0.00
336
100.00
337
