Danfoss VACON 3000 Application Manual page 62

VACON® 3000
Application Guide
Index Parameter
P3.5.3.2.2 RO1 ON De-
lay
P3.5.3.2.3 RO1 OFF
Delay
P3.5.3.2.4 RO2 Func-
tion
P3.5.3.2.5 RO2 ON De-
lay
P3.5.3.2.6 RO2 OFF
Delay
P3.5.3.2.7 RO3 Func-
tion
P3.5.3.2.8 RO3 ON De-
lay
P3.5.3.2.9 RO3 OFF
Delay
Table 57: Digital Output Settings on MV Star Board
Index Parameter
P3.5.3.6.1 RO1 Function
62 | Danfoss A/S © 2021.09
Min Max Unit De-
fault
0.00 320.00 s 0.00
0.00 320.00 s 0.00
0 56 4
0.00 320.00 s 0.00
0.00 320.00 s 0.00
0 56 2
0.00 320.00 s 0.00
0.00 320.00 s 0.00
Min Max Unit
0 21
ID Description
33 = Precharge ready
34 = Precharge started
35 = Precharge inhibit
36 = Precharge coil
37 = HXL coil
38 = MV HX coil
39 = LV HX coil
40 = MCB coil
11002
11003
11004 See P3.5.3.2.1.
11005 See P3.5.3.2.2.
11006 See P3.5.3.2.3.
11007 See P3.5.3.2.1. Not visible if only 2 output relays are installed.
11008
See P3.5.3.2.2. Not visible if only 2 output relays are installed.
11009
See P3.5.3.2.3. Not visible if only 2 output relays are installed.
Default ID Description
0 6040 0 = Not used
1 = Test (always closed)
2 = Ready
3 = Run
4 = Fault
5 = Fault inverted
6 = Alarm
7 = Fieldbus Control- Word B13
8 = Fieldbus Control- Word B14
9 = Fieldbus Control- Word B15
10 = Fieldbus Process- Data1.B0
11 = Fieldbus Process- Data1.B1
12 = Fieldbus Process- Data1.B2
13 = Main contactor permissive
14 = Main contactor close
INU Application
AB319735759636en-000101 / DPD01822
