VACON® 3000
Application Guide
Index Parameter
P3.1.5.10 Frequency filter time constant
P3.1.5.11 Flux reference
P3.1.5.12 FW control Kp
P3.1.5.13 FW control Ti
P3.1.5.14 Flux Ready Limit

4.5.2 Group 3.2: Start/Stop Setup

Table 35: Start/Stop Setup
Index Parameter
P3.2.1 Remote Control Place
P3.2.2 Local/Remote
P3.2.3 Keypad Stop Button
P3.2.4 Start Function
P3.2.5 Stop Function
P3.2.6 I/O A Start/Stop Logic
P3.2.7 I/O B Start/Stop Logic
P3.2.8 Fieldbus Start Logic
Danfoss A/S © 2021.09
Min Max
Min Max Unit Default
0
0 1
0
0 1
0 1 1
0 1 0
0 1 0
2
0 4
2
0 4
0 1 0
Unit Default ID
s 0.012 15647
% 100.0 1250
% 0.00 4027
s 0.0000 4028
% 0.0 4017
ID Description
172 0 = I/O control
1 = Fieldbus control
211 0 = Remote
1 = Local
114 0 = No
1 = Yes
505 0 = Ramping
1 = Flying start
506 0 = Coasting
1 = Ramping
Logic = 0
300
• Ctrl sgn 1 = Forward
• Ctrl sgn 2 = Backward
Logic = 1
• Ctrl sgn 1 = Forward (edge)
• Ctrl sgn 2 = Inverted Stop
• Ctrl sgn 3 = Bckwrd (edge)
Logic = 2
• Ctrl sgn 1 = Forward (edge)
• Ctrl sgn 2 = Bckwrd (edge)
Logic = 3
• Ctrl sgn 1 = Start
• Ctrl sgn 2 = Reverse
Logic = 4
• Ctrl sgn 1 = Start (edge)
• Ctrl sgn 2 = Reverse
363 See P3.2.6.
889 0 = A rising edge is necessary
AB319735759636en-000101 / DPD01822 | 51
INU Application
Description
